12" Explosion-proof Axial Fan Cylinder Pipe Spray Booth Paint Fumes Exhaust Fan

<p>Description：</p> <p>CBF series flameproof and explosion-proof axial-flow fans (hereinafter referred to as axial-flow fans) meet the standards and are suitable for factories and enterprises: containing. IIA, lIB, T1-T4 groups of explosive gas or vapor environment, as the ventilation and ventilation of factories and warehouses or to enhance heat dissipation.<br><br></p> <p>Specification:<br><br></p> <p>Model: CBF-300<br><br></p> <p>Rated voltage: AC 110V<br><br></p> <p>Power: 180W<br><br></p> <p>Impeller diameter: 300MM<br><br></p> <p>Spindle speed: 1450RPM<br><br></p> <p>Air volume: 2280m3/h<br><br></p> <p>Cable outer diameter outlet thread: 1/2<br><br></p> <p>Explosion-proof mark: Exdll BT4Gb<br><br></p> <p>Wind pressure: 60<br><br></p> <p>Noise: 62dB<br><br></p> <p>Weight: 10KG<br><br></p> <p>Packing Size: 48x48x35CM<br><br></p> <p>Features:<br><br></p> <p>Product identification is clear. Clear identification of product label, explosion-proof safety sign and safety precautions<br><br></p> <p>Cast aluminium fan blade design. Smooth operation, large air volume, low noise<br><br></p> <p>Strong explosion-proof motor. Pure copper coil, strong sealing, high-speed operation, enough power to ensure fan blade outflow<br><br></p> <p>Explosion-proof special cast iron motor housing. Hard and firm, strong corrosion resistance, not easy to oxidize<br><br></p> <p>Mesh metal protective net. It is safer to prevent the fan blades from being damaged after sundries are inhaled into the fan.<br><br></p> <p>Operation note:(Axial fan can be used reliably in the following environments)<br><br></p> <p>A) not exceeding 2000 m above sea level;<br><br></p> <p>B) operating ambient temperature - generally not lower than - 20C, not higher than + 40C;<br><br></p> <p>C) the relative humidity of the surrounding air is not more than 50% (+ 25C);<br><br></p> <p>D) in the factory with class II B explosive gas environment;<br><br></p> <p>E) no rain, snow and other liquid invading environment;<br><br></p> <p>F) Vertical or parallel to the horizontal surface to prevent tilt and rollover<br><br></p> <p>G) Axial fan should be stored in warehouse with good ventilation system<br><br></p> <p>H) Prevent rain and strong vibration during transportation<br><br></p> <p>Package:<br><br></p> <p>1 x 300mm Explosion-proof Axial Flow Fan</p>
